Bộ Phát Điện Năng Lượng Mặt Trời COMBO 5 Plus 12V

The COMBO5 Plus solar power kit is a new power source that does not require any fuel source, completely free and practical
– Providing uninterruptible power supply even when grid electricity is cut

1.490.000 1.290.000

Thanh toán ngay

SOLAR POWER

SOLUTIONS TO SAVE ELECTRICITY AND ENVIRONMENTAL PROTECTION

 COMBO5 Plus is a new source of energy when traditional sources of energy such as coal, oil are running out and unstable supply, many sources of energy are being considered and especially  solar source

Currently, with the rapid development of technology and scientific and technological advances,  solar  power is no longer a “luxurious” source of electricity for Vietnamese consumers. Due to being among the countries with the highest solar distribution of the year on the world’s solar radiation map, Vietnam has a huge potential for solar energy.

Principle of operation

Solar panels are a system of special material panels capable of converting the solar energy of sunlight into electricity. The panels are made of high-performance photovoltaic cells with a capacity of 20 – 175Wp and an average life of 30 years.

Operating principle from solar cells (solar cells), light is converted into electricity, creating direct current (DC Power). This current is directed to the controller (charge controller) is a device with a function that automatically regulates the current from the solar cell and the battery charging current (Battery). Through the DC / AC (Inverter) adapter, it  creates standard 220V / 50Hz alternating current to run household appliances such as lights, fans, televisions, computers, refrigerators, pumps.

Utilities that solar power brings:
– Solar energy does not require any fuel source, completely free and practical;
– Help you save money on electricity for your family monthly;
– Create an independent, clean and green power source;
– Providing uninterruptible power supply even when grid electricity is cut;

The use of solar power  as a local energy source to replace traditional forms of energy not only contributes to saving electricity for the family, reducing the growing demand for energy for the nation, but also contribute to economic development and national energy security.

Specifications

 (FULL SET OF COM BO PACKS WITH THE DEVICE AS FOLLOWS)

 Device name

Parameter

Amount

 Guarantee

Solar panels (Polycrystalline)

6V-5W Life expectancy of 25 years -> 50 years

The attached cord is 5 meters with clamps

01

15 years

Rectifier charger solar battery

 6V – 3A

01

1 year

Sealed battery

6V – 4.5Ah

01

1 year

Super bright led bulbs

6V – 5W

The attached cord is 5 meters with clamps

02

1 year

A convenient 10-port multi-function cable for charging multiple phones

500mnA-1000mnA

01

Control cabinet size: length * width * height

14.5cm * 7.5cm * 12.5cm

01

Time to use lighting

Fill the bottle: about 10h sunshine to meet the standards

– 1 5W Led bulb: 4h – 8h , – 2 Led bulbs 5W: 2h- 4h

Origin

SolarCity German technology European standards






Diagram principle of operation





Samyoung inverter 100W



Samyoung inverter 100W

Application

* Some pictures of the installation and application of the system:



Description: http://img191.imageshack.us/img191/4525/mattroi3.jpg

Description: http://img717.imageshack.us/img717/2023/slide0021image054.jpg

Description: http://img687.imageshack.us/img687/1830/daongocvung.jpg



To get the solar power system suitable for your family, please contact us at the following address to get the best price advice and support, we will advise and design the system. system in accordance with your request. In addition, we also design the system of high-voltage solar lamppost lighting for traffic, works, construction of concentrated solar power stations for places without grid power such as borders, islands, remote communes … with a capacity of 20Wp-1MWp.
